The vector network analyzer is the reference instrument for characterising the S-parameters of a component or a network, and its accuracy sets the ceiling on what a laboratory can prove. Many labs respond by buying a higher-grade VNA, which works but is expensive. A cheaper and often overlooked route starts one step earlier in the measurement chain: the printed circuit board that holds the device under test. A well-designed test board lets an existing instrument deliver more than its headline specification suggests. This article looks at where measurement accuracy is actually lost and how the PCB can recover it.
A VNA injects a known signal, then measures what is reflected and what is transmitted. Anything the test chain adds along the way is attributed to the device under test, so the errors come from three places:
The substrate sets the floor on what the fixture can achieve. Above a few GHz, standard FR-4 is not good enough, and the reason is not only its loss.
High-frequency laminates cost more than FR-4, but a fixture is a small board. Spending there is one of the better returns available in a lab budget, and the same thinking appears in our guide to inspection types and their roles in high-frequency PCBs.
With the material settled, the trace geometry becomes the main lever. Impedance should be calculated with a field solver rather than a two-dimensional calculator, then specified to the fabricator as a requirement with a tolerance. Every section from the connector to the device pad should sit as close to 50 ohm as the process allows.
Discontinuities are where reflections begin, and there are three standard ones on any test board.
A clean ground is the lifeline of any high-frequency design, and on a test board it also protects the measurement from the instrument’s own environment.
A perfect board can still be defeated by a poor calibration kit or a badly fitted connector, so the last few millimetres deserve the same attention as the trace itself.
SOLT standards implemented on the fixture have to be precise. An open needs compensation for the fringing capacitance at its end rather than a simple trace termination. A short needs a very low-inductance path to the ground plane. The load is the hardest of the three, and it is normally a broadband chip resistor soldered onto a carefully designed line so that the impedance stays resistive across the band.
Choose connectors rated for the test frequency, whether that means SMA, 3.5 mm or 2.92 mm. The outer shell needs a 360-degree low-inductance solder joint to the ground plane, and the centre pin has to meet the trace cleanly with no protrusion or misalignment. A connector that looks acceptable at low frequency can dominate the response at 30 GHz.
Before fabrication, simulate the complete fixture including connectors, traces and the device pads, so that impedance mismatches and resonances are found on screen rather than on hardware. Once the board exists, use it as its own reference. Measure a plain through line and look at the response: a good design holds S11 below -20 dB, sometimes -30 dB, across a wide band, and its S21 curve is smooth and matches what the simulation predicted. The same verification logic runs through impedance control in high-frequency manufacturing, where measured data is what closes the loop.
Improving measurement capability does not have to start with a purchase order for a better instrument. Material choice, trace geometry, grounding and connector work are all within the control of the engineer who lays out the fixture, and together they can recover accuracy that the instrument was already capable of delivering. The physics does not change with frequency, which is why the same discipline shows up in millimeter-wave design above 30 GHz and in the general materials question for microwave and RF boards. A fixture that respects it turns a good instrument into an accurate one.
Frequently Asked Questions
Because everything the fixture adds is attributed to the device under test. Impedance discontinuities, dielectric loss and stray coupling all appear as properties of the device, so a poor fixture limits the accuracy of even a very good instrument.
Below a few hundred MHz it can be. Above a few GHz it is not, because its loss tangent is high and its dielectric constant varies across the board, which corrupts both amplitude and phase measurements.
Treating the ground plane as a formality. Split ground planes, sparse stitching vias and long return paths create loops that radiate and couple, and the resulting errors look like device behaviour.
Because it must present a purely resistive impedance across the whole band. That requires a broadband resistor and a layout with minimal parasitic inductance, and any inductance left in the path shows up as a frequency-dependent error.
Measure a plain through line and inspect S11 and S21. Return loss below -20 dB over the band, and an insertion loss curve that matches simulation, indicate the fixture is not limiting the measurement.
